TECHNICAL DATA
22 – English
1153140-26 Rev. 2 2010-02-11
Technical data
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/EC.
Note 2: Equivalent sound pressure level, according to ISO 22868, is calculated as the time-weighted energy total for
different sound pressure levels under various working conditions. Typical statistical dispersion for equivalent sound
pressure level is a standard deviation of 1 dB (A).
Note 3: Equivalent vibration level, according to ISO 22867, is calculated as the time-weighted energy total for vibration
levels under various working conditions. Reported data for equivalent vibration level has a typical statistical dispersion
(standard deviation) of 1 m/s
2
.
235e 236e 240e 240e TrioBrake
Engine
Cylinder displacement, cm
3
34 34 38 38
Stroke, mm 32 32 32 32
Idle speed, rpm 3000 3000 3000 3000
Power, kW (Europe) 1,3 / 9000 1,4 / 9000 1,5 / 9000 1,5 / 9000
Power, kW (Australia) 1,3 / 9000 1,4 / 9000 1,5 / 9000 1,5 / 9000
Ignition system
Spark plug
Champion RCJ
7Y Champion RCJ
7Y Champion RCJ
7Y Champion RCJ
7Y
Electrode gap, mm 0,5 0,5 0,5 0,5
Fuel and lubrication system
Fuel tank capacity, litre 0,3 0,3 0,3 0,25
Oil pump capacity at 8,500 rpm, ml/min 7 7 7 7
Oil tank capacity, litre 0,20 0,20 0,20 0,20
Type of oil pump Automatic Automatic Automatic Automatic
Weight
Chain saw without bar or chain, empty tanks, kg 4,6 4,6 4,7 5,0
Noise emissions (see note 1)
Sound power level, measured dB(A) 112 112 113 113
Sound power level, guaranteed L
WA
dB(A) 118 118 118 118
Sound levels (see note 2)
Equivalent sound pressure level at the
operator’s ear, dB(A)
98,6 98,6 100,7 100,7
Equivalent sound pressure level at the
operator’s ear, dB(A) (Australia)
78 78 79 79
Equivalent vibration levels, a
hveq
(see note
3)
Front handle, m/s
2
2,4 2,4 2,1 2,1
Rear handle, m/s
2
3,9 3,9 2,7 2,7
Chain/bar
Standard bar length, inch/cm 16/40 16/40 16/40 16/40
Recommended bar lengths, inch/cm 12-18 / 31-46 12-18 / 31-46 12-18 / 31-46 12-18 / 31-46
Usable cutting length, inch/cm 11-17 / 29-43 11-17 / 29-43 11-17 / 29-43 11-17 / 29-43
Pitch, inch/mm 0,325/8,3 0,325/8,3 0,325/8,3 0,325/8,3
3/8 / 9,52 3/8 / 9,52 3/8 / 9,52 3/8 / 9,52
Thickness of drive links, inch/mm 0,050/1,3 0,050/1,3 0,050/1,3 0,050/1,3
Type of drive sprocket/number of teeth 7 7 7 7
Chain speed at max. power, m/sec 20,0 20,0 20,0 20,0
