Before Using Before Using
Names of the parts
Adjustable foot
(four pieces)
Power line
Water inlet valve
Water absorption
cushion
Drain hose joint
Meaning and description of the symbols
Warning sign
Prohibition sign
Contents marked with that symbol
are related to the safety of the
product and the personal safety
of the users. Please operate in
strict conformity to the contents,
otherwise it may cause damage
of the machine or injure the
personal safety of the user.
Contents marked with that symbol
are actions forbidden to perform.
Performing of those actions may
result in damage of the machine
or injure the personal safety of
the user.
Accessories
Honourable users:
Thank you for choosing our products.
Our products integrade high-tech, precision frontier science.To facilitate using it, please
read this manual carefully and operate this machine according to it.
Power switch
Program selector
Bleach injection inlet
Cabinet
Control panel
Control panel seat
Inner tub
Top lid
Water level knob
Control foot of door switch
Pulsator
Start/Pause switch
Outer drain
hose component
(one)
Drain hose
clamp
(one)
Door switch
the end connecting to
the water inlet hose jointer
the end connecting to
the washing machine
jointer connecting the
water inlet hose and
the water faucet
water inlet hose
(one)
Water inlet
hose jointer
(one)
Lint filter
(one)
