46
B. Optional Components
16 in.
(406 mm)
52 in.
(1321 mm)
1/2 in.
(13 mm)
20 in.
(508 mm)
66 in.
(1676 mm)
1/2 in.
(13 mm)
HX3 Hearth Extension
HX4 Hearth Extension
Bifold Glass Doors
DM1036, DM1042
AK24
Outside Air Kit
ID4 Insulated Duct
UD4 Uninsulated Duct
42 in.
(1067 mm)
4 in. (102 mm) i.d.
42 in.
(1067 mm)
4 in. (102 mm) i.d.
2 Wire Ties
Fastener Pack
4044-036 Air Kit Parts
Outside Air
Hood
Outside Air
Plate
Assembly
Heatilator • EL36/EL42 • 4044-132 • Rev V • 11/08
See your Heatilator dealer for a complete listing of optional components.
