Hoshizaki KM-1601MRH - Manual (Page 9)

9
Title: B. Water Circuit Model: KM-1601MRH/3
Index
No. Description
Material or
Model Number Part Number
Required Number
Q-0
to
R-1
S-1
to
A-0
A-1
B-0
Water Circuit
Order Assembly Parts Individually
Assembly Number for Reference Only
1A0094A06 1 1 1
1 Water Supply Pipe (includes
item 2) 4A5216G04 1 1 1
2 Water Supply Pipe Fitting Nut 468616-01 1 1 1
3 Rubber Gasket 413854-03 1 1 1
4 Water Valve 3U0111-02 1 1 1
5 Drain Valve Housing 435054-01 1 1 1
6 Spray Tube 1A0260-02 1 1 1
7 Spray Tube 1A0260-01 1 1 1
8 Spray Guide 208586-01 12 12 12
9 Cube Guide A 214905-01 1 1 1
10 Cube Guide B 322644-02 1 1 1
10a Thumbscrew 415949G12 1 1 1
10b Collar 435269-01 2 2 2
10c T2 Flat Head Screw 7P22-0416 2 2 2
11 Vinyl Hose L=58 7716-1519 1 1 1
12 Vinyl Hose L=63 7716-2025 2 2 2
13 Hose A 435091-01 1 1 1
14 Distributor 432426-01 2 2 2
15 Plug 4A0176-01 4 4 4
16 Drain Hose 435092-01 1 1 1
17 Drain Valve B 3A1170-01 1 1 1
18 "O" Ring 7611-G035 1 1 1
19 Spring 322685-01 1 1 1
20 Valve Seat 433705-01 1 1 1
21 Hose C 326655-01 1 1 1
22 Overflow Cap 322816-01 1 1 1
23 Overflow Pipe 322691-01 1 1 1
24 "O" Ring 4A1234-01 1 1 1
25 Float Switch Connector 426799-01 1 1 1
26 Float Switch 4A0886-02 1 -
4A3624-02 1 1
27 Connector 432763-01 1 1 1
28 Rubber Ring 439236-01 1 1 1
29 Silicone Hose L=80 7730I3812 1 1 1
30 Spring 435825-01 1 1 1
31 Vinyl Hose L=670 7716-2025 1 1 1
32 Vinyl Hose L=190 7716-2025 1 1 1
33 Tee 4A0177-01 1 1 1
34 Silicone Hose L=130 7730I3812 2 2 2
35 Bypass Hose 439265-01 1 1 1
36 Ball Valve Assembly (includes
items 37 through 39) S-0761 442137A01 1 1 1
37 Male Adaptor 325826-01 2 2 2
38 "O" Ring 7611-P018 2 2 - Replaced with thread sealant tape
39 Ball Valve 439293-01 1 1 1
