Hoshizaki KM-1601MRH - Manual (Page 5)

5
Title: A. Ice Cuber Assembly & Refrigeration Circuit Model: KM-1601MRH/3
Index
No.
Description
Material or
Model Number Part Number
Required Number
Q-0
R-0
R-1
to
U-0
U-1
to
A-0
A-1
B-0
Ice Cuber Assembly
Order Assembly Parts Individually
Assembly Number for Reference Only
KM-1601MRH 1A0600A05 1 1 1 1
KM-1601MRH3 1A0600A06 1 1 1 1
1 Front Panel 2A2164-02 1 1 1 1
2 Gasket L=762 4A0808L02 1 1 1 1
3 Top Panel 3A1941A01 1 1 1 1
4 Right Side Panel 2A2165G01 1 1 1 1
5 Front Insulation 322711G01 1 1 1 1
6 Top Insulation 322714G01 1 1 1 1
7 Control Box Cover 3A2386-01 1 1 1 1
8 Junction Box Cover 433410-01 2 2 2 2
9 Bin Control Bulb Holder 322815G02 1 1 1 1
9a Thumbscrew 415949G10 2 2 2 2
10 Bin Control Bulb Holder 328919-01 1 -
3A3903-01 1 1 1
11 Spacer 443545-01 2 -
12 Silicone Hose L=285 7730I3812 1 1 1
13 Run Capacitor KM-1601MRH
35MFD,
370VAC 3A2005-05 1 1 1 1
14 Start Capacitor KM-1601MRH
145-175MFD,
250V 3A0076-01 1 1 1 1
15 Start Relay (Starter) KM-1601MRH 4A1107-09 1 1 1 1
16 Main Transformer KM-1601MRH3 4A0817-01 1 1 1 1
Refrigeration Circuit
Order Assembly Parts Individually
Assembly Number for Reference Only
KM-1601MRH 1A0242A07 1 -
1A1247A01 1 -
1A1830A01 1 1
KM-1601MRH3 1A0242A08 1 -
1A1247A02 1 -
1A1830A02 1 1
17 Compressor
(A-1 and later utilize external
crankcase heater - item 18) KM-1601MRH 4A2334-02 1 1 1 -
4A2334-01 1
KM-1601MRH3 4A2330-02 1 1 1 -
4A2330-01 1
17a Grommet 434922-01 4 4 4 4
17b Spacer 434921-01 4 4 4 4
17c Bolt 8×45 437889-01 4 4 4 4
18 Crankcase Heater 434186-01 1
19 Receiver 440366-01 1 1 1 1
19a Hex Head Bolt w/Washer 5×10 7B0130510 3 3 3 3
20 Evaporator (includes item 21) 104442G03 1 1 1 1
21 Evaporator Plate 103317G01 4 4 4 4
22 Thermostatic Expansion Valve 4A1482-01 2 2 2 2
23 Thermostatic Expansion Valve
Cover 3A0944-01 2 2 2 2
