Heat & Glo • FB-IN-S, FB-GRAND-S • 783-910 Rev. G • 11/08 25
LOG #2 (SRV773-702):
Position Log #2 onto grate such that tab C fi ts into the slot on bottom surface of log.
LOG #3 (SRV768-704):
Position log #3 onto grate such that the tab D fi ts into the slots on bottom surface of log
and the right back side of log is fl ush against tab E.
LOG #4 (SRV573-702):
Place log #4 into the fl at spot on the log #1 and the left side of the log will rest on log #2
as shown.
Flat Spot for Log #4
2 2
3 3
4 4
1 1
2 2
3 3
