All the cables shall have got the local
authentication certificate.
6. The breaker of the air conditioner should
be all-pole switch; and the distance between
its two contacts should be no less than
3mm. Such means for disconnection must
be incorporation in the fixed wiring.
7. The waste battery shall be disposed
properly.
8. The appliance is not intended for use
young children or infirm persons without
super vision.
9. Young children should be supervised to
ensure that they do not play the appliance.
2
Do not obstruct or cover the ventilation
grille of the air conditioner. Do not put
fingers or any other things into the
inlet/outlet and swing louver.
Do not allow children to play with the air
conditioner. In no case should children be
allowed to sit on the outdoor unit.
Specifications
The refrigerating circuit is leak-proof.
The machine is adaptive in following
situation:
1.Applicable ambient temperature range:
2. If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similar qualified person.
3. If the fuse on PC board is broken, please
change it with the type of T 3.15A /250VAC.
4. The wiring method should be in line with
the local wiring standard.
5. The power cable and connecting cable
are self-provided.
The requirement of the connecting cable:
Cooling
Heating
Indoor
outdoor
Rated Maximum Minimum
27 32 18
19 23 14
35 43 10
24 26 6
20 27 15
14.5 -- --
7 24 -15
6 18 --
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C
Cautions
Model
Power cable: H05RN-F 3G 2.5mm
2
AD092XLERA
AD122XLERA
AD142XLERA
AD182XLERA
Connecting cable
Signal wires: H05RN-F 2X1.5mm
2
