5
Explanations:
The following illustration is for your convenience to recognize where all
terminals are located and to connect peripheral equipment; due to the
product improvement, the indications may be different from the actual
one. The actual indications shall prevail.
Side control panel
Side control panel
2
3
4
1
5
INPUT
Explanations on the keys on the side of the TV set and their
functions
1 INPUT: Recall / Close the signal source menu.
2 MENU: Used to recall / Exit menu, etc.
3 VOL+/-:
In TV mode: Increase (+) or decrease (-) volume;
In TV menu: Move right (+) or move levt (-) in the options.
4 CH▲/▼:
In TV mode: Select the next channel (▲) or the previous channel (▼);
In TV menu: Move up (▲) and down (▲) in the options; while in standby
mode, the Channel▲/▼ may be used to turn on the TV set.
5 : Standby On/Off key
Panel control and rear terminal control
