Side signal source interfaces
CVBS 2/
S-VIDEO IN
S-VIDEO
VIDEO
R
L
Earphone socket:
The user may use the earphone via the earphone socket.
CVBS-2 /S-VIDEO
input:
Connect the VIDEO outputs or S-VIDEO outputs of DVD player,
LCD player, video recorder or video camera, etc. to the VIDEO
input or S-VIDEO input of the TV set. (S-VIDEO is shared with the
CVBS audio)
Audio input:
Connect the audio signal source (PC, DVD player, LCD player,
video recorder or video camera, etc.) to the audio input port.
