MAINTENANCE
24 1740274
HOW TO REPLACE THE AUGER
1. Remove the belt cover. See “How To Remove The Belt
Cover”.
2. Remove the drive belt. See “How To Replace The Drive
Belt”.
3. Use a 1-inch wrench and remove the auger pulley
from the auger shaft (threads are left hand; turn clock-
wise to remove). (See Figure 22).
4. To keep the auger from rotating, set a 2”x4” piece of
wood on the center paddle to secure auger.
5. Use a 7/16-inch wrench and remove the fasteners from
the bearing assembly. Remove the bearing assem-
bly from the auger housing.
6. Slide the auger out of the bearing assembly on the
right side of the snow thrower.
7. Tip the auger enough to allow the auger to slide out of
the auger housing.
8. To install auger, reverse the above steps.
Figure 22
Bearing Assemlby
Auger Pulley
Auger Housing
Auger
Center Paddle
Wood
