2
3 4
A typical NEC MultiSync MD
Series display system configuration
1 Single or dual head displays
2 Display controller board
3 GammaComp MD quality
control software
4 Calibrator (optional)
1
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
MultiSync is a registered trademark of NEC Display Solutions. All
other brand or product names are trademarks or registered trademarks
of their respective holders. Product specifications subject to change.
4/09 Ver. 2.
©2009 NEC Display Solutions of America, Inc. All rights reserved.
NOTE 1: American College of Radiology (ACR) recommends minimum
of 171 cd/m 2
Model
LCD Viewable Image Size
LCD Module Technology
Active Screen Area
Native Resolution
Pixel Pitch
Brightness at Native (typical)
Contrast Ratio (typical)
Response Time (typical)
Viewing Angle (typical) (up/down/left/right)
Grayscale Tone
Input Connectors
Selectable Gamma
Factory calibration
X-Ray film simulation
Power Supply
Power Consumption (typical)(120V)
Power Savings
Tilt / Swivel Stand
Height Adjustable Stand
Pivot Enabled Stand
VESA Mounting
Dimensions (WxHxD)
Bezel Width
Net Weight, including stand
Regulatory Standards
Display Video Cards (preferred)
Remote Network Sensor (optional)
Colorimeter
Limited Warranty*
Extended Warranty (addtl. 1 yr./addtl. 2 yr.)
MultiSync MD205MG
20.1"
SA-Superfine Grayscale TFT Glass
31.9 x 39.9 cm
2560 x 2048 Landscape/2048 x 2560 Portrait
0.156mm
850 cd/m 2 max / 400 cd/m 2 calibrated
600:1
30ms
85°/85°/85°/85°
10-bit: 1024 shades of gray from a pallet of 3061
DVI-D
DICOM, log-linear, 2.2 and programmable
Gamma correction according to DICOM GSDF with
automatic adjustment
Clear Base
Internal, AC 100-240V, 50/60 Hz nominal
65W
<3W
+30°, -5° / 340°
120mm
Yes
100 x 100mm
18.7 x 18.3 x 9.7 in. / 474.3 x 465.3 x 247.3mm (Landscape)
14.9 x 20.2 x 9.7 in. / 379.6 x 512.7 x 247.3mm (Portrait)
28mm
25.8 lbs. / 9.8 kg.
UL2601/EN60601-1/EC601, FCC part 15 class B, CE/MDD,
PCT, C-tick, PCBC/B Mark, PSB, EnergyStar, GEEA Energy
Label, DIN 6868-57, FDA-510K
MDRV10B-5MP
Sentry DX (MD-N2M5B)
GammaComp MD Sensor (MDSVSENSOR)
5 years parts and labor, including Advanced Overnight
Exchange
EW1-MD2MP21 / EW2-MD2MP21
Industry-leading
standard limited warranty
• 5 years
• Advanced Overnight
Exchange ships a replacement
monitor to arrive the next
business day with NEC
covering the cost of shipping
both ways
Display video card
Bus Interface
Output Signal
Display Resolutions (portrait)
Dot Clock
Maximum Power Consumption
System Requirements
Compatible OS
Host Processor Frequency
Main Memory
MDRV10B-5MP
PCIe x 1
DVI x 2 / 8- or 10-bit grayscale
2048 x 2560 (single head) / 4096 x 2560 (dual head)
165 Mhz
25.8W
Microsoft Windows XP / 2000 / XP x64
500 MHz or greater
256 MB or greater
* Backlight usage limited to 30,000 hours at 400 cd/m 2 or less
