HP DC7900 - Manual (Page 34)

Frequency Band Frequency Band Frequency Band Frequency Band 2.4 GHz and 5 GHz
Antenna Structure Antenna Structure Antenna Structure Antenna Structure 1 transmit; 2 receive (1x2)
Data Rates Data Rates Data Rates Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (draft): 66 possible data rates, ranging from 6 Mbps to 300 Mbps,
depending on the combination of Bandwidth, Modulation Coding Scheme,
and Guard Interval used, as defined in IEEE 802.11n (draft) specification
Modulation Modulation Modulation Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security Security Security Security 1 Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES
(support for key sizes of 128, 192, and 256 bits), 802.1x authentication
types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows Vista and XP only.
Sub-channels Sub-channels Sub-channels Sub-channels Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol Media Access Protocol Media Access Protocol Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture Network Architecture Network Architecture Network Architecture
Models
Models Models Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming Roaming Roaming Roaming IEEE 802.11 compliant roaming between access points
Output Power Output Power Output Power Output Power (for CCK) 2 15 dBm
Output Power Output Power Output Power Output Power (for OFDM;
power varies by data
rate)
2
15 dBm
Power Consumption Power Consumption Power Consumption Power Consumption Transmit: 2.3 Watts (average, with one spatial streams)
Receive: 1.9 Watts (average with two receive chains)
Idle mode
3 : 30 mW (average)
Radio off: 20 mW (max)
Power Management Power Management Power Management Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity Receiver Sensitivity Receiver Sensitivity Receiver Sensitivity 4 300 Mbps: -68 dBm, 54 Mbps: -74 dBm, 6 Mbps: -90 dBm
Antenna Connections Antenna Connections Antenna Connections Antenna Connections 3 U.FL type connectors, 50 ohm nominal impedance
Range Range Range Range 802.11 a – Typical
(@6 Mbps) 600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps) 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps) 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor Form Factor Form Factor Form Factor PCI-Express MiniCard
Weight Weight Weight Weight 0.013 lb (6 g)
Dimensions Dimensions Dimensions Dimensions 0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage Operating Voltage Operating Voltage Operating Voltage 3.3V +/- 9%, 1.5V +/- 5%
Temperature Temperature Temperature Temperature Operating
Non-operating 32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
QuickSpecs
HP Compaq dc7900 Business PC HP Compaq dc7900 Business PC HP Compaq dc7900 Business PC HP Compaq dc7900 Business PC
Technical Specifications - Communications
DA - 13029 North America — Version 15 — March 30, 2009 Page 34
