User’s Guide A–1
A
Specifications
f2304 Flat Panel Monitor
Display
Type 23 inches
Wide screen TFT
LCD 58.4 cm
Viewable Image Size 23-inch diagonal 58.4 cm
Tilt –5 to 20 o
Face Treatment Anti-glare
polarizer with
hard coating
Maximum Weight (unpacked) 20.9 lbs. 9.5 kg
Dimensions (includes pedestal
Height (maximum)
Depth
Width
16.9 inches
7.8 inches
25.3 inches 428 mm
197 mm
642 mm
Maximum Graphics
Resolution 1920 x 1200 (60 Hz) digital input,
Reduced Blanking Mode only
1920 x 1200 (60 Hz) analog input
Text Mode 720 x 400
Dot Pitch 0.258 x 0.258 mm
Horizontal Frequency 30 to 94 KHz
Vertical Refresh Rate 48 to 85 Hz
Operating Temperature
Non-operating Temperature 41 to 95 o F
–4 to +140 o F
5 to 35 o C
–20 to +60 o C
