44
Select Readouts
(Advanced, Sonar View Only)
Select Readout s sets individual digital readouts on
the Sonar View. This Advanced feature allows you
to select what data will be displayed in each of
either 5 or 6 (depending on your model) fixed-
position data windows arranged around the left
and bottom edges of the Sonar View screen, or
whether a particular window will be turned off,
displaying nothing in that area; you can access this
menu choice only when in Advanced User Mode
(see Setup Menu Tab: User Mode.)
Data windows can display readouts from supported accessories such as Temp/Speed.
Each data window can either be empty or contain one of the following:
- Speed (will be displayed if a Temp/Speed Accessory is attached and the
paddlewheel has moved at least once, or if a GPS Receiver is connected)
- Temperature
- Triplog (will be displayed if a Temp/Speed Accessory is attached and the
paddlewheel has moved at least once, or if a GPS Receiver is connected)
- Voltage
- Water Speed (will only be displayed if a Temp/Speed Accessory is attached
and the paddlewheel has moved at least once). Water Speed is not available
with a GPS receiver.
Select Readouts
