36
Water Type
(Advanced)
Water Type configures your unit for operation in fresh or salt water. The Water Type
menu choice is available when User Mode is set to Advanced (see Setup Menu Tab:
User Mode
).
NOTE: In salt water, what would be considered a large fish might be 2 to 10 times bigger
than a large fish in fresh water (depending on the type of fish you are seeking). The salt
water setting allows for a greater range in fish size adjustment to account for this. Also,
make sure that the Water Type is set accurately, especially in salt water, as this affects the
accuracy of deep water depth readings.
To change the Water Type setting:
1. Make sure you are in Advanced User Mode, then highlight Water Type on
the Sonar main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the Water Type
setting. (Fresh, Salt, Default = Fresh)
Transducer Select
(QuadraBeam® Only)
Transducer Select allows you to select which transducer you want to use .
NOTE: The Matrix 37 supports the WideSide transducer which requires a separate
purchase. You can visit our website at www.humminbird.com to order the WideSide
transducer online or contact our Customer Resource Center at 1-800-633-1468.
NOTE: The WideSide View will be added to the view rotation when a WideSide transducer
is connected to the Matrix 37 and Transducer Select is set to WideSide. In addition, Wide
Side View and Side Beam Range will be added to the X-Press
TM Menu. WideSide Sensitivity
will be added to the Sonar Tab of the main menu system.
To change the selected Transducer:
1. Highlight Transducer Select on the Sonar Main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the transducer
selected. (QuadraBeam, WideSide, Default = QuadraBeam)
