IT3800/3900 User’s Guide 7 - 5
Concatenation
Codabar supports symbol concatenation. When you Enable concatenation, the
scanner looks for a Codabar symbol having a “D” start character, adjacent to a
symbol having a “D” stop character. In this case the two messages are
concatenated into one with the “D” characters omitted. Default = On.
Select Require to prevent the scanner from decoding a lone Codabar symbol.
Codabar Message Length
Scan the bar codes below to change the message length. Refer to Message
Length Description (page 7-2) for additional information. Minimum and
Maximum lengths = 2-60. Minimum Default = 4, Maximum Default = 60.
A12D D34A
Codabar
Character Stop Start Stop Start
* On
Off
Require
Minimum Message Length
Maximum Message Length
