12 - 6 IT3800/3900 User’s Guide
Word Length: Data Bits,
Stop Bits, and Parity
*7 Data, 1 Stop, Parity Even 232WRD3 2-10
7 Data, 1 Stop, Parity None 232WRD0 2-10
7 Data, 1 Stop, Parity Odd 232WRD6 2-10
7 Data, 1 Stop, Parity Mark 232WRD12 2-10
7 Data, 1 Stop, Parity Space 232WRD9 2-10
7 Data, 2 Stop, Parity Even 232WRD4 2-10
7 Data, 2 Stop, Parity None 232WRD1 2-10
7 Data, 2 Stop, Parity Odd 232WRD7 2-10
7 Data, 2 Stop, Parity Mark 232WRD13 2-10
7 Data, 2 Stop, Parity Space 232WRD10 2-10
8 Data, 1 Stop, Parity Even 232WRD5 2-10
8 Data, 1 Stop, Parity None 232WRD2 2-10
8 Data, 1 Stop, Parity Odd 232WRD8 2-10
8 Data, 1 Stop, Parity Mark 232WRD14 2-10
8 Data, 1 Stop, Parity Space 232WRD11 2-10
RS-232 Handshaking
*RTS/CTS Off 232CTS0 2-12
RTS/CTS On 232CTS1 2-12
*XON/XOFF Off 232XON0 2-12
XON/XOFF On 232XON1 2-12
*ACK/NAK Off 232ACK0 2-12
ACK/NAK On 232ACK1 2-12
Wand Emulation Connec-
tion Same Code Format WNDPAT0 2-12
*Code 39 Format WNDPAT1 2-12
Wand Emulation Transmis-
sion Rate
10 WNDSPD0 2-13
*25 WNDSPD1 2-13
40 WNDSPD2 2-13
80 WNDSPD3 2-13
120 WNDSPD4 2-13
150 WNDSPD5 2-13
200 WNDSPD6 2-13
Wand Emulation Polarity
*Black High WNDPOL0 2-14
White High WNDPOL1 2-14
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
