13 - 6 IT3800/3900 User’s Guide
Standard Cable Pinouts (Primary Interface Cables)
Serial Output
10 Pin RJ41 Modular Plug connects to the scanner handle
1 2
C
ord shield
3
T
ied to 5 Volt power
4
S
upply ground
5
R
eceive data - Serial data to scanner
6
T
ransmit data - Serial data from scanner
7
5
Volt power connection
8
R
equest to send data
9
C
lear to send data
10
Decoded output data format pr
ovided at 10 pin RJ41 modular
connector (in scanner handle).
