Item 400V class Specifications
EU version 030HFEF 040HFEF X200 inverters,
400V models
USA version – 040HFU
kW 3.0 4.0 Applicable motor size *2
HP 4 5
380V 5.1 5.6 Rated capacity
(kVA) 480V 6.4 7.1
Rated input voltage *6 3-phase: 380V-15% to 480V ±10%, 50/60Hz ±5%
EU version SFE series : EN61800-3 category C2 filter Integrated EMC
filter USA version –
Rated input current (A) 10.0 11.0
Rated output voltage *3 3-phase: 380 to 480V (proportional to input voltage)
Rated output current (A) 7.8 8.6
Starting torque *7 100% at 6Hz
20%:
≤
60Hz Dynamic braking,
approx. % torque
(short time stop
from 50/60Hz) *8
Capacitive feedback type, dynamic braking unit and braking
resistor optional, individually installed
Braking
DC braking Variable operating frequency, time, and braking force
Kg 2.4 2.4 EU version
(-HFE) lb 5.30 5.30
Kg – 2.3
Weight
USA version
(-HFU)
lb – 5.08
1−9
