C102 Reset selection

Determines response to Reset input

[RS].
Three option codes:
00

…Cancel trip state at input

signal ON transition, stops

inverter if in Run Mode

01

…Cancel trip state at signal OFF

transition, stops inverter if in

Run Mode

02

…Cancel trip state at input ON

transition, no effect if in Run Mode

114Ah

0, 1, 2

−

C141 Input A select for logic

output

R/W

1150h

C142 Input B select for logic

output

R/W

See

“Output Logic and Timing” on

page 3–63

1151h

0, 1, 2, 3,

4, 5, 6, 7,

8, 10, 43

−

C143 Logic function select

R/W Applies a logic function to calculate

[LOG] output state, Three options:
00

…[LOG] = A AND B

01

…[LOG] = A OR B

02

…[LOG] = A XOR B

1152h

0, 1, 2

−
