Hyundai HQL260WR User Manual
Page 28
CONNECTIONS
25
Before connecting the video connections to external devices .....
Please make sure to read the following information on connection to enjoy best picture quality.
Video connectors
Types of video cable :
➀ 15-Pin D-SUB ➁ COMPONENT ➂ S-VIDEO ➃ COMPOSITE ➄ FULL SCART ➅ HALF SCART
Best picture quality is displayed in the following order.
Full Scart supports Composite simultaneously
15 Pin-D-Sub
COMPONENT
FULL SCART
>
>
>
S-VIDEO
COMPOSITE
HALF SCART
The superior picture quality starts from the far left side.
