SJ100 Inverter
Conf
igur
ing
Dr
iv
e P
a
ra
m
e
ters
3–43
“H” Group: Motor Constants Functions
Introduction
The “H” Group parameters configure the
inverter for the motor characteristics. You
must manually set H_03 and H_04 values to
match the motor. The remaining parameters
are related to sensorless vector control (SLV),
and are in use only when function A_44 is set
for SLV as shown in the diagram. The proce-
dure in
“Auto-tuning for Sensorless Vector
Control” on page 4–35 automatically sets all
the parameters related to SLV. If you config-
ure the inverter to use SLV, we highly recommend letting the auto-tuning procedure
derive the values for you. If you want to reset the parameters to the factory default
settings, use the procedure in
“Restoring Factory Default Settings” on page 6–8 .
NOTE: The auto-tuning procedure and related warning messages are in “Auto-tuning
for Sensorless Vector Control” on page 4–35 . Please read these before trying to auto-
tune the motor parameters.
Output
Inverter Torque Control Algorithms
A 44
V/f control,
constant torque
V/f control,
variable torque
Sensorless vector
(SLV) control
00
01
02
“H” Function
Run
Mode
Edit
Defaults
Func.
Code
Name /
SRW Display
Description
–FE
(CE)
–FU
(UL)
–FR
(Jpn)
Units
H_01 Auto-tuning Setting Three states for auto-tuning
function, option codes:
00... Auto-tuning OFF
01... Auto-tune (rotate motor)
02... Auto-tune (measure motor
resistance and inductance,
without rotating)
✘
00 00 00 —
AUX AUTO NOR
H_02 Motor data selection Two selections, option codes:
00... Use standard motor data
01... Use auto-tuning data
✘
00 00 00 —
AUX DATA NOR
H202 Motor data selection,
2nd motor
Two selections, option codes:
00... Use standard motor data
01... Use auto-tuning data
✘
00 00 00 —
2AUXDATA NOR
H_03 Motor capacity Nine selections:
0.2 / 0.4 / 0.75 / 1.5 / 2.2 / 3.7
5.5 / 7.5 / 11
✘
Specified by the
capacity of each
inverter model
kW
AUX K 0.4 kW
H203 Motor capacity, 2nd
setting
Nine selections:
0.2 / 0.4 / 0.75 / 1.5 / 2.2 / 3.7
5.5 / 7.5 / 11
✘
Specified by the
capacity of each
inverter model
—
2AUXK 0.4 kW
H_04 Motor poles setting Four selections:
2 / 4 / 6 / 8
✘
4 4 4 poles
AUX P 4p
