10
INTR
ODUC
TION
IMPOR
TANT
PRE
CA
UTIONS
BEF
ORE
YOU
BE
GIN
TREADMILL OPER
ATION
LIMITED
W
ARR
ANTY
TR
OUBLE
SHOO
TING
&
MAINTENANCE
CONDITIONING
GUIDELINE
S
AS
SEMBL
Y
BEF
ORE
YOU
BE
GIN
AS
SEMBL
Y
11
INTR
ODUC
TION
IMPOR
TANT
PRE
CA
UTIONS
TREADMILL OPER
ATION
CONDITIONING GUIDELINE
S
TR
OUBLE
SHOO
TING
&
MAINTENANCE
LIMITED
W
ARR
ANTY
ELEVATION FRAME
PRE-ATTACHED BOLT
PRE-ATTACHED NUT
RIGHT LINKAGE ARM
BOLT (I)
TEFLON WASHER (J)
RIGHT CONSOLE MAST
PRE-ATTACHED TEFLON WASHER
ASSEMBLY STEP
RIGHT HANDLEBAR
CONSOLE MASTS
BOLTS (K)
FLAT WASHERS (L)
ARC WASHERS (N)
SPRING WASHERS (M)
SPRING WASHERS (M)
BOLTS (K)
CONSOLE CABLE
BOLT (K)
20 mm
Qty: 6 FLAT WASHER (L)
8 mm
Qty: 4 SPRING WASHER (M)
8 mm
Qty: 6 ARC WASHER (N)
8 mm
Qty: 2
HARDWARE BAG CONTENTS:
CABLE HOLE
CONSOLE CABLE
RIGHT CONSOLE MAST
RIGHT HANDLEBAR
PULSE CABLE
POWER CABLE
CONSOLE CABLE
ASSEMBLY STEP 2
Open HARDWARE BAG 2.
Attach LOCK LATCH PIN (G) to RIGHT FOLDING
FRAME using T-wrench and tighten completely.
Pull LEAD WIRE through RIGHT CONSOLE MAST. After pulling the lead wire through the mast, the top
of the console cable should be located at the top of the mast. Detach and discard lead wire.
Insert 1 BOLT (D) and 1 FLAT WASHER (E) through RIGHT CONSOLE MAST followed by 1 WAVY WASHER
(F) and attach to MAIN FRAME.
Unscrew PRE-ATTACHED NUT and remove from RIGHT LINKAGE ARM and discard. Carefully move
RIGHT LINKAGE ARM and PRE-ATTACHED TEFLON WASHER into position to attach to ELEVATION
FRAME.
While holding RIGHT CONSOLE MAST in the upright position, attach RIGHT LINKAGE ARM using BOLT
(I) and TEFLON WASHER (J) as shown.
A
B
C
D
E
F
Open HARDWARE BAG .
With the running deck in the
lowered position, place the
RIGHT HANDLEBAR on top of
the RIGHT CONSOLE MAST.
Carefully route the CONSOLE
CABLE through the bottom
of the handlebar and out the
CABLE HOLE as shown in
second drawing below. The
PULSE CABLE and POWER
CABLE should be pulled out of
the hole as well.
NOTE: Do not pinch the
CONSOLE CABLE when placing
right handlebar on top of the
RIGHT CONSOLE MAST.
To assemble the RIGHT
HANDLEBAR to the RIGHT
CONSOLE MAST, insert
2 BOLTS (K), 2 SPRING
WASHERS (M) and 2 FLAT
WASHERS (L) in the inside
of the mast and 1 BOLT (K),
1 SPRING WASHER (M) and 1
ARC WASHER (N) in the rear
of the mast as shown.
Repeat on other side.
NOTE: Only the pulse cable
will need to be routed through
the cable hole on the left
handlebar.
A
B
C
D
NOTE: Carefully align holes
when assembling handlebars to
console mast, making sure to
not press down on handlebars.
NOTE: Do not completely
tighten any screws or bolts
until step 6 is complete!
NOTE: Do not completely tighten any
screws or bolts until step 6 is complete!
HARDWARE BAG 2 CONTENTS :
LOCK LATCH
PIN (G)
Qty: 1 WAVY WASHER (F)
29 mm
Qty: 1
BOLT (D)
Qty: 1
FLAT WASHER (E)
27 mm
Qty: 1
BOLT (I)
Qty: 1 TEFLON WASHER (J)
Qty: 1
RIGHT CONSOLE MAST
LEAD WIRE
CONSOLE CABLE
LOCK LATCH PIN (G)
ELEVATION FRAME
BOLT (D)
FLAT WASHER (E)
WAVY WASHER (F)
