Heat & Glo • PIER-HV-IPI, ST-HV-IPI, L&R-COR-HV-IPI • 2005-900 Rev. M • 9/08 9
Service Parts List (NG, LP) LCOR-HV-IPI
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Set Assembly / Burner Pre Sept 2008 SRV2005- 006 X
Log Set Assembly Post Sept 2008 LOGS-MSR X
1 Log 1 SRV2005- 701
2 Log 2 SRV2005- 700
3 Log 3 SRV2005- 702
4 Log 4 SRV2005- 703
5 Log 5 SRV2005- 704
6 Log 6 SRV2005- 705
7 End Glass Assembly GLA-MS X
8 Refractory SRV2005- 731
Log Set Assembly / Burner Pre Sept 2008 SRV2005- 006 X
Burner NG, LP Post Sept 2008 2005-006 X
10 Glass Door Assembly GLA-6TROC X
11 Grate Assembly 2005-012
12 Refractory SRV2005- 730
Ember Mesh Assembly 2006-008
Exhaust Baffle 385-128
Fiberglass Rope 060-455
Glass Latch Assembly 386-122A X
Junction Box 4021-013 X
Lava Rock 2005-790
Mineral Wool 050-721
Non-Combustible Board (end) 2008-114
Non-Combustible Board (side) 2006-136
Pilot Tube 446-301 X
Teco-Sil, 5lb. Bag 700-790
Touch Up Paint TUP-GBK-12
Conversion Kit NG NGK-MS X
Conversion Kit LP LPK-MS X
Pilot Orifice NG 446-505 X
Pilot Orifice LP 446-517 X
Regulator NG NGK-DXV X
Regulator LP LPK-DXV X
Additional service part numbers appear on following page.
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed in
this manual may be ordered from an authorized dealer.
Stocked
at Depot
