D. Service Parts

06/08

Service Parts

Service Parts Diagram

36 in. W

o

odburning Fireplace

Part number list on following page.

EXCLAIM-36H, EXCLAIM-36T

Beginning Manufacturing Date: March 2004

Ending Manufacturing Date:

Active

1

3

4

5

6

7

8

9

2

Traditional

Herringbone

Refractories

06/08

Service Parts

Service Parts List

36 in. W

oodburning Fireplace

Beginning Manufacturing Date: March 2004

Ending Manufacturing Date:

Active

IMPOR

TANT

: THIS IS DA

TED INFORMA

TION. When requesting service or replacement

parts for your appliance please provide model number and serial number

. All parts listed

in this manual may be ordered from an authorized dealer

.

Stocked

at Depot

ITEM

D

ESCRIPTION

COMMENTS

P

A

RT NUMBER

1

S

tarter Section

Assembly

22072B

Y

2

Damper Blade

Assembly

29964

N

3

Damper Control

20549

N

Damper W

eight

19785A

N

4

Rear T

op

Standof

f

Qty

. 2 req.

19228

N

5

F

ront T

op

Standof

f

Qty

. 2 req.

11

864i

N

6G

ra

te

GR37

N

7

Upper Front

4013-206

N

8

S

moke Shield

32949

Y

9

F

irescreen Assembly

4013-122

Y

Firescreen Handle

1 ea.

4021-149

N

Firescreen Rod

Qty

. 2 req.

12052

N

Grate Retainer

Qty

. 2 req.

4017-046

N

Nailing Flange

Qty

. 4 req.

31

190

N

Outside Air

Kit

AK22

N

Fastener Pack

17916B

N

Outside Air

Shield

33271

Y

4 in. Outside

Air Inlet Ring

25692

N

Refractory Retainer

Qty

. 3 req.

11

847

N

Screen Cover (top only)

Qty

. 2 req.

31319

N

Side T

rim

Qty

. 2 req.

31326

N

Strip Protector

Qty

. 2 req.

18320

N

Powder Coat

To

uch-Up Paint

71479

N

Herringbone Refractory (EXCLAIM-36H)

Herringbone Brick Refractory - Back

4013-054

N

Herringbone Brick Refractory - Hearth

4013-050

N

Herringbone Brick Refractory - Left Side

4013-056

N

Herringbone Brick Refractory - Right Side

4013-055

N

Tr

aditional Refractory (EXCLAIM-36T)

T

raditional Brick Refractory - Back

4013-051

N

T

raditional Brick Refractory - Hearth

4013-050

N

T

raditional Brick Refractory - Side

Qty

. 2 req.

4013-052

N

Installation Instructions & Owner's Manual

4013-251

N

EXCLAIM-36H, EXCLAIM-36T
