51
TR-TVK
TR Top Vent Kit
Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev C • 11/08
TR11/TR444 - Round Termination Cap
TR11T/TR442 - Round Telescoping Termination Cap
ST1175/ST475 - Square Termination Cap
TCT1175 - Terra Cotta Cap
15-3/4 in.
(400 mm)
32-3/8 in.
(822 mm)
34-3/8 in .
(873 mm)
14-3/4 in.
(375 mm)
23 in.
(584 mm)
23 in.
(584 mm)
9-3/8 in.
(238 mm)
9-1/4 in.
(235 mm)
17 in.
(432 mm)
20 in.
(508 mm)
26 in.
10 3/4 in.
CT-11A
