Names of the part s
Before using Before using Before using Before using
Meaning and description of the symbols
Accessories
Contents marked with
that symbol are related
t o t h e s a f e t y o f t h e
product and the personal
safety of the users. Failure
t o c o m p l y w i t h t h e
instruction could cause
damage of the machine
o r i n j u r e t h e p e r s o n a l
s a f e t y o f t h e u s e r .
Warning
mark
Top lid
Control panel
Lint filter(Installed by user)
Control panel film
Pulsator
Cabinet
Base frame
Adjustable foot
seam
Adjustable foot
Inner drain hose
Power line
Inner tub
Cabinet handle
Back cover
Water level Switch
Control panel film
Water valve
Bottom plate
(1 piece)
The end connecting to
the washing machine
The end connecting to
the water inlet hose jointer
Jointer connecting
the water inlet hose
to the water faucet
Water inlet hose
(2 pieces)
Water inlet
hose jointer
(2 pieces)
Tapping screw
ST4x 16
(1 pieces)
Drain hose
(1 pieces) Hose clamp
(1 pieces)
Lint filter
(1 piece)
Contents marked with
that symbol are actions
f o r b i d d e n t o p e r f o r m .
F a i l u r e t o c o m p l y w i t h
t h e i n s t r u c t i o n c o u l d
result in damage of the
m a c h i n e o r i n j u r e t h e
personal safety of the user.
Forbidding
mark
