August 1, 2008 Page 47 Heat & Glo · Tiara I B & Tiara II B · 7010-149M
C. Vent Components Diagram
Figure 12.3 SL-D Series Vent Components
4 in. (102 mm) inner pipe 6-5/8 in. (168 mm) outer pipe
9-1/4 in.
(235mm)
6-1/2 in.
(165mm)
6-5/8 in.
(168mm)
17-24 in.
(432-610mm)
11-3/4 in.
(298mm)
5-3/4 in.
(146mm)
6-5/8 in.
(168mm)
6-3/8 in.
(162mm)
6-1/2 in.
(165mm)
9-5/8 in.
(244mm)
6-5/8 in.
(168mm)
6-1/2 in.
(165mm)
6-3/8 in.
(162mm)
9-5/8 in.
(244mm)
SLP6M
SLP12M
SLP12AM
SLP45-BK
SLP90M
3-3/4 in.
(95mm)
12-17 in.
(305-432mm)
35-3/4 in.
(908mm)
23-3/4 in.
(603mm)
47-3/4 in.
(1213mm)
SLP4M SLP48M SLP36M SLP24M SLP6AM
