Hafler MAQ-104 - Manual (Page 4)

Hinged top provides easy access to crossover modules.
> Detailed owner’s manual located conveniently inside
hinged top.
> Cosmetically "clean” look enhances any installation.
> Mounting holes concealed internally.
Output sensitivity adjustment.
> Insures compatibility with any radio or head piece.
> Independent adjustment per channel.
NOMENCLATURE
Refer to figure 1 for the location of the inputs, outputs,
potentiometers, and various switches used in the con-
figuration of the MAQ-104.
Front/Rear defeat switch: These two switches will either
make the MAQ-104 circuitry active or bypass it completely.
See Figure 1 for active/defeat positions.
Delay switch: These dip switches are used to program the
remote turn-on delay period.
Frequency band boost and cut: Each adjustment poten-
tiometers on the MAQ-104 will allow you to boost by turning
any potentiometer clockwise, and cut by turning counter
clockwise.
WARNINGS
To prevent possible system damage, please follow the
guidelines below.
> Never connect or disconnect any component of the
sound system while power is applied to the system.
> Prolonged exposure to high sound pressure levels
can cause hearing impairment - please use common
sense when listening to your auto sound system.
2
