APPLICATIONS
4 CHANNEL OPERATION
4 Channel operation is accomplished by using all 4 inputs
and outputs. Figures 2-3 show typical hook up examples.
2 CHANNEL OPERATION
2 channel operation of the MAC-104 uses only 2 of the 4
inputs. Figures 4-5 show some typical examples.
2 CHANNEL X 2 OPERATION
(DUAL CURVE)
This is accomplished by feeding the source outputs into
both inputs of the MAQ-104. Next tie both the MAQ-104
outputs together. The dual curve option is then produced
by making either the front channels active and the rear
channels active. The reverse is also possible. See Figure
6 for hook up example.
This type of option is well suited for convertible cars that
have their hoods up or down.
For those people that share
a car but have different listening styles, this dual option is
also nice.
NOTE 1: This option is only two channel operation.
NOTE 2: By having both front and rear active at one time
you will have little or no output.
