SPECIFICATIONS
The MAQ-104 is deliberatdy restricted to 12 dB of boost or
cut per band. This is meant to discourage attempts to
correct large system response problemswith the equalizer.
System response errors greater than about 6 dB over a
span of an octave or more should be corrected elsewhere
in the system, by correcting speaker or amplifier problems.
Excessive use of equalization is likely to overdrive
amplifiers, speakers, or other components.
INPUTS
Input Level = 750mV RMS
Input Impedance = 20K Ohms
OUTPUTS
Output Level = 750 mV RMS
ELECTRICAL
Output Impedance =500 Ohms
Distortion = Less than .01% THD + N
Signal to noise ratio = over 90 dB (A-weighted)
Filter Q = 2 typical
Power Required = less than 1 amp at 12 volts typical.
PHYSICAL
Dimensions = 8.000H x 10.125W x 1.75D.
Weight = 3 Ibs.
