46
C. Chimney Components
Heat & Glo • EM-415, EM-485 • 33056 • Rev AF• 7/12
SL315/SL330 Offset/Return
A
B
14-1/2 in.
(368 mm)
Ceiling Firestop
Assembled
Diameter: 14 1/2 in./368 mm
Height: 24 in./610 mm
AS8 Straight Attic Insulation Shield
JB877 Chimney Joint Band
10-1/2 in.
(267 mm)
CB876 Chimney Joint Band
RF371 Roof Flashing
RF370 Roof Flashing
Catalog # A B
FS338 0-deg. 14-1/2 in. 368 mm
FS339 15-deg. 18-3/8 in. 467 mm
FS340 30-deg. 23 in. 584 mm
2 in. (51 mm)
10-1/2 in.
(267 mm)
24-5/8 in.
(625 mm)
27-3/8 in.
(695 mm)
12 in.
(305 mm)
31 in.
(787 mm)
24-5/8 in.
(625 mm)
12 in.
(305 mm)
Inside
Diameter
8 in. (203 mm)
Outside
Diameter
10-1/2 in.
(267 mm)
Effective
Height
4-3/4 in.
(121 mm)
TR344 Round Termination Cap
15-3/4 in.
(400 mm)
TCT375 Terra Cotta Cap
22 1/2 in.
(572 mm)
9 1/2 in.
(241 mm)
16 1/2 in.
(419 mm)
9 1/2 in.
(241 mm)
