Figure 4.6
Figure 4.7
V
H2
H1
H2
V
H1
Natural Gas • Two 90
0
Elbows System
V Min.
H1 Max.
H1 + H2 Max.
460 mm
550 mm
1.1 M
920 mm
1.1 M
2.3 M
1.4 M
1.7 M
3.5 M
1.8 M
2.2 M
4.5 M
V+H1+H2 = Max 10M H1 Max = 2.2M H1+H2 = Max 4.5M
Propane • Two 90
0
Elbows System
V Min.
H1 Max.
H1 + H2 Max.
460 mm
390 mm
690 mm
920 mm
750 mm
1.3 M
1.4 M
1.1 M
2.1 M
1.8 M
1.5 M
2.7 M
V+H1+H2 = Max 10M H1 Max = 1.5M H1+H2 = Max 2.7M
Natural Gas • Two 90
0
Elbows System
V Min.
H1 Max.
H1 + H2 Max.
460 mm
550 mm
1.1 M
920 mm
1.1 M
2.2 M
1.4 M
1.7 M
3.5 M
1.8 M
2.2 M
4.5 M
V+H1+H2 = Max 11.0M H1 Max = 2.2M H1+H2 = Max 4.5M
Propane • Two 90
0
Elbows System
V Min.
H1 Max.
H1 + H2 Max.
460 mm
390 mm
690 mm
920 mm
750 mm
1.3 M
1.4 M
1.1 M
2.1 M
1.8 M
1.5 M
2.7 M
V+H1+H2 = Max 10.6M H1 Max = 1.5M H1+H2 = Max 2.7M
