Vh h v – Heat & Glo Fireplace VRTIKL-AU User Manual
Page 11
11
Heat & Glo • VRTIKL-AU • 2123-900 • 7/07
Figure 4.4
Figure 4.5
V
H
H
V
Natural Gas • One 90
0
Elbow System
V Minimum
H Maximum
460 mm
1.3 M
920 mm
2.7 M
1.4 M
4.1 M
1.8 M
5.0 M
V+H = Max 11.6 M H Max = 5.0 M
Propane • One 90
0
Elbow System
V Minimum
H Maximum
460 mm
920 mm
920 mm
1.8 M
1.4 M
2.8 M
1.8 M
3.6 M
V+H = Max 11.6 M H Max = 3.6 M
Natural Gas • One 90
0
Elbow System
V Minimum
H Maximum
460 mm
1.3 M
920 mm
2.7 M
1.4 M
4.1M
1.8 M
5.0 M
V+H = Max 11 M H Max = 5.0 M
Propane • One 90
0
Elbow System
V Minimum
H Maximum
460 mm
920 mm
920 mm
1.8 M
1.4 M
2.8 M
1.8 M
3.6 M
V+H = Max 11 M H Max = 3.6 M
