D. Service Parts (continued)
D. Service Parts
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Starter Section Assembly 22069B Y
2 Damper Kit 4044-029 Y
3 Damper Weight 19785A
4 Damper Rod 28900
5 Damper Blade Assembly 4044-030
6 Damper Control 4044-152
7 Top Standoff Qty 4 req 4044-111
8 Door Track (used for upper) 15427
9 Smoke Shield 4044-120
10 Refractory Retainer Qty 3 req 11847
11 Side Refractory Qty 2 req 4044-114
12 Back Refractory 4044-113
13 Hearth Refractory 4044-112
14 Hearth Retainer 4044-109
15 Grate Retainer Qty 2 req 4044-170
16 Grate GR40 Y
17 Firescreen Assembly 4044-027 Y
18 Firescreen Rod
1 piece 4044-172
2 Piece (Qty 2 req) 12052 Y
19 Firescreen Handle 1 ea 10002
Door Pivot Clip Qty 2 req 31527
Extended Smoke Shield Kit 4044-180
Fastener Pack 4025-023
Smoke Shield Kit Installation Instructions 4044-165
Nailing Flange Qty 4 req 4044-161
Smoke Baffle Qty 2 req 4044-116
Strip Protector 18320
Hair Pin Clip Pkg of 24 101025/24 Y
Installation Instructions and Owner's Manual 4044-132
Beginning Manufacturing Date: Jan 2005
Ending Manufacturing Date: Active
EL42
Service Parts List
Heatilator • EL36/EL42 • 4044-132 • Rev AD• 7/12
