51
D. Service Parts
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Starter Section Assembly 22069B Y
2 Damper Kit 4044-029 Y
3 Damper Weight 19785A
4 Damper Rod 28900
5 Damper Blade Assembly 4044-030
6 Damper Control 4044-152
7 Top Standoff Qty 4 req 4044-111
8 Door Track (used for upper) 15425
9 Smoke Shield 4044-131
10 Refractory Retainer Qty 3 req 11847
11 Side Refractory Qty 2 req 4044-114
12 Back Refractory 4044-130
13 Hearth Refractory 4044-129
14 Hearth Retainer 4044-128
15 Grate Retainer Qty 2 req 4044-170
16 Grate GR41 Y
17 Firescreen Assembly Qty 2 req 4044-028 Y
18 Firescreen Rod
1 piece 4044-175
2 Piece (Qty 2 req) 11866B Y
19 Firescreen Handle 10002
Door Pivot Clip Qty 2 req 31527
Extended Smoke Shield Kit 4044-179
Fastener Pack 4025-023
Smoke Shield Kit Installation Instructions 4044-165
Hair Pin Clip Pkg of 24 101025/24 Y
Nailing Flange Qty 4 req 4044-161
Smoke Baffle Qty 2 req 4044-116
Strip Protector Qty 2 req 18320
Installation Instructions and Owner's Manual 4044-132
ELEMENT Woodburning Fireplace
Service Parts List Beginning Manufacturing Date: Jan 2005
Ending Manufacturing Date: Active
EL36
Heatilator • EL36/EL42 • 4044-132 • Rev AD• 7/12

