Heatilator • Caliber BV Series • 4040-262 Rev J • 10/08 3
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
Table of Contents
A. Congratulations 2
B. Warranty 5
1 Listing and Code Approvals
A. Appliance Certifi cation 7
B. Tempered Glass Specifi cations 7
C. BTU Specifi cations 7
D. High Altitude Installations 7
E. Non-Combustible Materials Specifi cation 7
F. Combustible Materials Specifi cation 7
G. Electrical Codes 7
User Guide
2 Operating Instructions
A. Gas Fireplace Safety 8
B. Your Fireplace 8
C. Fan Kit (optional) 9
D. Clear Space 9
E. Decorative Doors and Fronts 9
F. Fixed Glass Assembly 9
G. Remote Controls, Wall Controls and Wall Switches 9
H. Outside
Air (optional) 9
I. Before Lighting Fireplace 9
J. Lighting Instructions (IPI) 10
K. After Fireplace is Lit 11
L. Frequently Asked Questions 11
3 Maintenance and Service
A. Maintenance Tasks-Homeowner 12
B. Maintenance Tasks-Qualifi ed Service Technician 13
Installer Guide
4 Getting Started
A. Typical Appliance System 14
B. Design and Installation Considerations 15
C. Tools and Supplies Needed 15
D. Inspect Appliance and Components 15
E. Negative Pressure 16
5 Framing and Clearances
A. Selecting Appliance Location 17
B. Constructing the Appliance Chase 17
C. Clearances 18
D. Mantel and Wall Projections 19
6 Termination Locations
A. Vent Termination Minimum Clearances 20
7 Vent Information and Diagrams
A. Vent Guidelines 21
B. Vent System Confi guration 21
8 Vent Clearances and Framing
A. Pipe Clearances to Combustibles 22
B. Wall and Ceiling Penetration Framing 22
C. Vertical Penetration Framing 22
9 Appliance Preparation
A. Install Outside Air Kit Damper Assembly 23
B. Gas and Electrical Connections 23
C. Secure and Level the Appliance 23
10 Installing Vent Pipe
A. Assembly of Vent Sections 24
B. Attach Vent to Firebox 24
C. Secure Vent Sections 24
D. Install Attic Insulation Shield 24
11 Gas Information
A. Fuel Conversion 25
B. Gas Pressure 25
C. Gas Connection 25
D. High Altitude Installations 25
12 Electrical Information
A. Wiring Requirements 26
B. Intellifi re Ignition System Wiring 26
C. Optional Accessories Requirements 26
D. Electrical Service and Repair 26
E. Junction Box Installation 27
F. Wall Switch Installation for Fan (Optional) 27
13 Finishing
A. Mantel and Wall Projections 28
B. Facing Material 28
