Iii. technical information, A. water circuit and refrigeration circuit, Km-901mah (air-cooled) – Hoshizaki KM-901MWH User Manual
Page 37
37
III. Technical Information
A. Water Circuit and Refrigeration Circuit
1. KM-901MAH (air-cooled)
Water Supply
Cleaning Valve
Float Switch
Drain
Check Valve
Expansion Valves
Compressor
Hot Gas
Valve
Check
Valves
High Pressure
Switch
Strainer
Fan
Drier
Condenser
Evaporator
Access
Valve
Discharge Line
Suction Line
Water Pump
Thermistor
Spray Tubes
Inlet Water Valve
Freeze
Pump-Out
Water
Tank
Access Valve
Refrigeration Circuit
Water Circuit
