3. KM-901MRH/3 (remote air-cooled)
Receiver Tank
Water Supply Inlet
Junction Boxes
Drier
Control Box
Spray Tubes
Control Switch
Water Pump
Float Switch
Compressor
Expansion Valves
Hot Gas Valve
Liquid Line Valve
Cleaning Valve
Thermostatic Bin Control
Auxiliary Code T-0, U-0
Thermostatic Bin Control
Bracket & Bulb Holder
Auxiliary Code T-0, U-0
Mechanical Bin Control and Bracket
Auxiliary Code U-1 and later
