Specifications
MODEL: URC-9F
Note: We reserve the right to make changes in specifications and design without prior
notice.
AC SUPPLY VOLTAGE
115/60/1 (Connection to Icemaker)
FAN MOTOR
115 V
Total 1.3FLA
65W
EXTERIOR DIMENSIONS (WxDxH)
32-3/16" x 15-11/16" x 21-15/16" (817 x 398 x 558 mm)
DIMENSIONS INCLUDING LEGS (WxDxH)
34-5/16" x 18-1/8" x 36-15/16" (871 x 460 x 938 mm)
EXTERIOR FINISH
Galvanized Steel
WEIGHT
Net 81 lbs. ( 37 kg ) Shipping 92 lbs. ( 42 kg )
CONNECTIONS - ELECTRIC
Permanent - Connection
- REFRIGERANT
Discharge Line 1-1/16"-12 UNF Fitting (#10 AEROQUIP)
Liquid Line 5/8"-18 UNF Fitting (#6 AEROQUIP)
CONDENSER
Air-cooled, Fin and tube type
FAN MOTOR PROTECTION
Thermal Protection
REFRIGERANT CONTROL
Condensing Pressure Regulator
REFRIGERANT CHARGE
R-404A
3 lbs. 14.8 oz. (1780g)
DESIGN PRESSURE
High 467 PSIG
OPERATING CONDITIONS
VOLTAGE RANGE
104 ~ 127 V
AMBIENT TEMP.
-20 ~ 122 °F
ACCESSORIES -SUPPLIED
Leg
2 pcs
Hex. Head Bolt w/Washer 8 x 16
8 pcs
Hex. Nut
8
8 pcs
