Hardware Reference Guide www.hp.com 1-7
Hardware Upgrades
Installing Additional Memory
The computer comes with double data rate 2 synchronous dynamic
random access memory (DDR2-SDRAM) dual inline memory
modules (DIMMs).
DIMMs
The memory sockets on the system board can be populated with up to
two industry-standard DIMMs. These memory sockets are populated
with at least one preinstalled DIMM. The sockets are labeled DIMM1
and DIMM2. To achieve the maximum memory support, you can
populate the system board with up to 2GB (2 x 1GB) of memory.
DDR2-SDRAM DIMMs
For proper system operation, the DDR2-SDRAM DIMMs must be:
■ industry-standard 240-pin
■ unbuffered PC2-5300 667 MHz-compliant
■ 1.9 volt DDR2-SDRAM DIMMs
The DDR2-SDRAM DIMMs must also:
■ support CAS latency 4 (CL = 4) for PC2-5300 667 MHz
■ contain the mandatory JEDEC SPD information
In addition, the computer supports:
■ 256Mbit, 512Mbit, and 1Gbit non-ECC memory technologies
■ single-sided and double-sided DIMMS
■ DIMMs constructed with x8 and x16 DDR devices; DIMMs
constructed with x4 SDRAM are not supported
✎
The system will not start if you install unsupported DIMMs.
