54
SPECIFICATIONS
Dimensions
Engine
Generator
ITEM MAINTENANCE SPECIFICATION
Tuneup Specifications
193.1 lbs (87.6 kg)
28.4 in (721 mm)
27.2 in (691 mm)
40.9 in (1,040 mm)
EAMC
192.0 lbs (87.1 kg)
Non-California type
(AN type)
California type
(AC type)
Model
Type
Description code
Length
Width
Height
Dry mass [weight]
Model
Type
Engine type
Displacement
[Bore
Stroke]
Compression ratio
Engine speed
Cooling system
Ignition system
Oil capacity
Fuel tank capacity
Spark plug
Model
Rated voltage
AC Rated frequency
output Rated current
Rated output
Maximum output
DC output
Spark plug gap
Valve clearance
Other specifications No other adjustments needed.
IN: 0.15 0.02 mm (cold)
EX: 0.20 0.02 mm (cold)
Refer to page 41
See your authorized
Honda dealer.
0.028 0.031 in (0.7 0.8 mm)
Only for charging 12V automotive batteries.
Maximum charging output
8.3A
3.8 kVA
3.3 kVA
27.5/13.8 A
60 Hz
120/240 V
BPR5ES (NGK) W16EPR-U (DENSO)
1.2 US qt (1.1 )
Transistorized magneto
Forced air cooling
3,600 rpm
8.2 : 1
2.9 2.3 in (73.0 58.0 mm)
14.8 cu-in (242 cm )
California type
(AC type)
Non-California type
(AN type)
GX240
6.21 US gal (23.5 )
,
EM3800SX
EM3800SX
[ ]
Specifications may vary according to the types, and are subject to
change without notice.
4-stroke, overhead valve, single cylinder
