Harman Stove Company Magnafire Series Coal Stoves - Mark I - Manual (Page 18)

3-90-70746R11_06/13
Service Parts
Mark II
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPoRTANT: THIS IS DATED INFoRMATIoN. When requesting service or replacement parts for
your appliance please provide model number and serial number. All parts listed in this manual may
be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Ash Door, Roped 1-10-08142A
Ash Pan 1-10-00722 Y
baffl e 2-00-00360b
blower - 75cfm, 7ft Cord 3-21-07584 Y
brick 9” X 4-1/2” x 1-1/4”
Pkg of 7 1-00-900450125 Y
414 Pcs 3-40-900450-414
brick, Set of cut 1-00-00837 Y
brick Angle Qty 2 req 2-00-01100-2S
brick bracket 2-00-01006
Door Handle Cast 4-00-00042 Y
Door Hinge Qty 4 req 2-00-07203D
Door Latch 4 Sets 1-00-00036 Y
Door Pin 3/8 x 2-1/4 (Load Door) Pkg of 4 4-30-00138A Y
Gasket 1/2” Round Rope (Load Door - Ash Door) 20 Ft 1-00-53500 Y
Gasket Glue, 32 oz 3-42-4583
Gasket, 5/8” Channel (glass) 5 Ft 1-00-98187 Y
Grate Holder - Cast Qty 2 req 3-00-00193 Y
Grate Link 2 - Cast 3-00-00203 Y
Hot Water Coil 3-10-49201
Hot Water Coil Hardware 3-10-49000
Load Door Top Cast 4-00-00034-1
Load Door Top (Gold) No longer available 3-00-00034-4
Mag Grate 20” - Cast Qty 2 req 3-00-00211 Y
Mag Leg - Cast 4-00-00044P
Screw, Hex Cap, 5/16-18 x 3/4” Grade 5 Zinc Plated Pkg of 100 3-30-1125-100 Y
Shaker bar Weldment 1-1/2” 1-10-02015W Y
Shaker block 2-00-01037-1 Y
Shaker Handle Mount 2-00-01037-2 Y
Short Door Pin 3/8 x 1-7/8 (Ash Pan) Pkg of 4 4-30-00138b Y
Touch Up Paint, Aerosol black 3-42-1990
Washer, Split Lock, 5/16” Zinc Plated Pkg of 100 3-30-0101-100 Y
