5. Install rod (8) thru holes in bottom pole section (3)
and eyebolt (7) as shown.
7
7.
9
Pole
12
Bring pole foward and secure pole to front panel (4) at 34” (86.4 cm) mark on pole. Tighten nuts evenly until
snug. NOTE: Equal rotations on each side of u-bolt are necessary. (Final adjustment to level the rim will
be made in step 27).
Pole
34”
(86.4 cm)
Mark
8
6.
Insert pole into base assembly as shown.
NOTE: Two people recommended for this step.
Tilt unit foward using caution and secure pole
bottom to base using nut (12) and disk (13),
a deep socket is recommended.
8.
13
12
9
7
10
12
10
TOP VIEW OF
BASE ASSEMBLY
IMPORTANT!
DO NOT OVER
TIGHTEN.
IMPORTANT!
Make sure items (10)
and (11) are used in
this assembly.
7
11
2
1
3
3
4
4
4
6
5
11
BOTTOM VIEW OF FRONT PANEL ASSEMBLY
SIDE VIEW OF ASSEMBLY
