20 SYSTEM CONFIGURATION

System Configuration

To set the delay times, follow these steps:

1. Put the AVR 110 in the Dolby Pro Logic

mode by pressing the Surround Mode
Selector

7 on the front panel or by

pressing the Surround Mode Selector
j on the remote, until PRO LOGIC
appears in the Main Information Display
W and the PRO LOGIC indicator F
lights up.

2. Press the Delay button

the remote or front panel. The words
S DELAY TIME will appear in the
Main Information Display

3. Press the Set button

4. Adjust the delay time by pressing the

⁄

buttons

on the remote or the

Selector buttons

5 on the front panel

until the delay time figure calculated using
the formula entered above appears in the
display.

5. If only analog sources will be used, no

adjustment is needed for the center-channel
delay. In that case, press the Set button
o

to enter the surround delay settings

into the AVR 110’s memory. However, if you
will be using digital sources and the calcu-
lations outlined above indicate that the
center-channel delay requires an adjust-
ment, continue with the following steps.

6. Before setting the center-channel delay

time, make certain that a digital source has
been selected. If a digital source is playing,
COAXIAL

E or OPTICAL B will appear

in the Information Display

. If a digi-

tal source is already connected and play-
ing, press the Delay button

and

then the

⁄

buttons on the remote

mq or the front panel Selector
buttons

5 until the words C DELAY

TIME appear in the Main Information
Display

and proceed to Step 10. If a

digital source is not playing, follow Steps 7
through 10.

7. Press the Set button

8. Select the Dolby Digital mode either by

pressing the front panel Surround Mode
Selector

7 or by pressing the Surround

Mode Selector

j on the remote on the

remote until DOLBY DIG appears in the
Main Information Display

9. Press the Delay button

the remote or front panel. The words
S DELAY TIME appear in the
Main Information Display

10. Press the

⁄

buttons

mq on the

remote once, so that C DELAY TIME
appears in the Main Information Display
W or in the on-screen display.

11. Press the Set button

12. Press the

⁄

buttons

on the

remote or the Selector buttons

5 on

the front panel until the desired delay
time for the center channel appears in the
display.

13. Press the Set button

to enter the

setting into the AVR 110’s memory.

You have now completed the setup, adjustment
and calibration of the AVR 110. You are now
ready to enjoy the finest in music and home-
theater listening.
