61-86-03-13
Page 5
Set Up Group Configuration Parameter Selections/Settings
SET LOCK  Enables lock
out or access to selected
set up group parameters
and calibration values.
LOCKID – Set Security Password
LOCK – Lock Out
READ STATUS 
Displays failsafe condition
and the results of various
diagnostics performed
during power up.
FAILSF – Failsafe
RAMTST – RAM Test Diagnostic
SEETST – Serial EEPROM Test
Diagnostic CFGTST – Configuration Test Diagnostic
CALTST – Calibration Test Diagnostic
SET DRVINF  Allows
access to actuator device
information.
VERSON – Firmware Version
SPEED – Stroke Speed
POWER – Power Input Voltage and Line
Frequency
TAG – Tag Name MFGDAT – Manufacturing Date
LREP – Date of Last Repair
LCAL – Date of Last Field Calibration
REPTYP – Repair Type
SET MAINT  Allows
access to parameters that
monitor operating
conditions.
TEMP – Actuator Temperature
TEMPHI – High Temperature Limit
TEMPLO – Low Temperature Limit
ACST – Accumulated Motor Stall Time
STARTS – Accumulated Motor Starts RLnCNTS – Relay Cycle Counts
REGNn – Accumulated Motor Starts
(Regions of Travel)
TOTDEG – Total Degrees of Motor Travel
MANRST – Reset Maintenance Statistics
Specifications – General
Physical
Enclosure Precision-machined ductile iron with corrosion resistant paint
Gear Train Precision-machined double reduction worm gear
Operating Temperature -30 °C to +65 °C (-20 °F to +150 °F)
except Model 11287S which has a range of: -20 °C to +65 °C (-4 °F to +150 °F)
Storage Temperature -40 °C to +93 °C (-40°F to +200 °F)
Relative Humidity 0-99% R.H. noncondensing, over the full operating temperature range.
Crank Arm Adjustable radii (8” to 14”) crank arm is standard
Rotation Factory set to 90 degrees, for 0% to 100% travel
Direction of Rotation Field programmable via local display and keypad
Manual Handwheel Provides a means of positioning the actuator in the event of a power failure or set-up
Lubrication Mobil Synthetic bearing and gear lubricant SHC 634 (ISO 460) or equivalent
Weight 300 lb to 600 lb (136 kg to 272 kg)—See Table below for more information.
Specifications continued on next page ⇒
