HP 100EU SFF PC - Manual (Page 3)

Base Unit One (1) drive bays and one PCI ex1 expansion slot
92 x 92 x 25 mm chassis fan
System board with Intel Pineview CPU and NM10 Chipset, Intel GMA graphic controller,
Realtek RTL8103EL 10/100 Fast Ethernet controller, Realtek ALC887 AUDIO codec, (1)
PCI ex1 slot, 2 DDR2 SO- DIMM memory slots, (2) Serial ATA data connectors
PSU Adapter & Power cord
Slots PCI ex1 One (1) half-height PCI ex 1 slot
Memory Expansion Two (2) DDR2 SO-DIMM slots (4 GB maximum memory support)
Bays External One (1) 5.25"
USB Support EHCI high-speed USB 2.0 controller
Two (2) front ports; Four (4) rear ports, Two (2) internal ports on system board
Interfaces One (1) analog VGA video port
One (1) rear line in; one (1) rear line out; one (1) rear mic in, (1) front mic in, (1) front headphone
out
One (1) RJ45 network port
Weight & Dimensions Chassis Dimensions
(H x D x W) 9.21 x 10.54 x 4.41 in
234 x 260 x 112 mm
Packaged Dimensions
(L x H x W) 19.48 x 12.99 x 8.50 in
495 x 330 x 216 mm
System Weight 22.4 lb (10.2 kg)
Shipping Weight 30.8 lb (14.0 kg)
Technology and
Features Memory Type PC2-6400 DDR2 SO- DRAM (800 MHz) non-ECC
Up to 4-GB maximum system memory supported
Hard Drive Interfaces
Supported Serial ATA
QuickSpecs
Compaq 100eu SFF PC (EMEA only)
System Details
DA - 13687 Worldwide QuickSpecs — Version 2 — 6.23.2010 Page 3
