Page 83
113674_0711
7-19
60" Deck
NOTES:
1. Do not torque nut; the discharge chute must pivot freely.
2. Torque to 118 ft-lbs.
3. Torque to 10 ft-lbs.
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
112933
1
PULLEY COVER RS 60"
2
112934
1
PULLEY COVER LS 60"
3
792002
4
KNOB 5/16-18 X 3/4"
4
602988
1
BELT, B-SEC 171.25 EL
5
602891
1
DISCHARGE CHUTE LG
6
602435
1
TORSION SPRING
7
602432
1
CHUTE PIN
8
086660
7
NT .375-16 HXZY NL
9
113563
1
BACKING PLATE
10
602817
1
RUBBER BUMPER
11
079210
2
FW .344 X 1.00 X.06 Z
12
064014
2
CS .312-18 X 0.875 HX G5
13
767954
6
FW .406 X .812 X .060 SAE
14
113180
1
INNER WALL ADJ RS 60"
15
025395
6
CB .375-16 X 1.00 STD CD
16
113179
1
INNER WALL ADJ LS 60"
17
794685
3
BLADE, F20.50"-H-F-CW
18
782474
3
CW .631 X 2.250 X .187 PNT
19
601983
3
CS .625-11 X 2.25 HXG5ZY
