113674_0711 5-3
Kawasaki FX691V & FX730V Engine
NOTES:
1. Supplied with the engine.
2. Part of the mower’s main wire harness.
3. Contains a 40 amp fuse.
4. Torque the bolt to 30 ft-lbs. Replace (do not reuse) the capscrew if
removed or loosened. Use only hand tools to install this fastener.
INDEX NO. PART NO. QTY. DESCRIPTION
1 N/A 1 KAW FX691V ENGINE
N/A 1 KAW FX730V ENGINE
2 788943 1 AIR FILTER INDICATOR
3 601216 1 ELBOW STREET FITTING
4 603326 17" 3/16" VAPOR LINE
5 603112 2 CLAMP, 3/16"
6 796524 1 OIL DRAIN VALVE
7 787713 3" HOSE, 0.50" LOW PRESSURE
8 602772 1 MUFFLER
9 029751 2 CS .375-16 X 1.000 HXFLK
10 705137 4 FW .391 X 1.250 X .060 ZNY
11 113970 1 CABLE GUIDE
12 000398 1 CLAMP
13 768523 2 FW .343 X .687 X .051/.080 HD
14 034272 1 NT .312-18 HX G5 ZNYC
15 034280 1 CS .312-18X .750 HX G5
16 767954 4 FW .406 X .812 X .060 SAE
17 602580 4 CS .375-16 X 1.25 HXG5 P85
18 016899 2 NT .375-16 HXFLK ZNYC
19 789131 1 FAN CAP
20 000331 3 WIRE TIE, SMALL/SHORT
21 786632 1 RED POSITIVE BATTERY CABLE
22 029876 1 LW .312 INT-EXT TOOTH Z
23 744284 1 NEGATIVE BATTERY CABLE
24 768523 1 FW .343 X .687 X .051/.080H
25 720516 3 CS M8 X 1.25 X 16 G10.9 HX
26 015818 12" 1/4" FUEL LINE
27 000323 2 HOSE CLAMP
