Fuel System-Tanks & Fuel Lines (with Carbon Canister)
NOTES:
1. Torque to 20 ft-lbs
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
602916
2
RATCHETING GAS CAP, 3.5"
2
602989
1
RS FUEL TANK
3
602990
1
LS FUEL TANK
4
000323
12
HOSE CLAMP
5
015818
131"
1/4" FUEL LINE
6
745059
1
FUEL VALVE 3-WAY
7
712919
10
FW .406 X 1.00 X.12 HRD Z
8
055822
10
CS .375-16 X .750 HX G5
9
034280
7
CS .312-18 X .750 HX G5
10
768523
14
FW .343 X .687 X .051/.080H
11
043570
3
LOOP CLAMP
12
034272
7
NT .312-18 HX G5 ZNYC
FUEL LINE LENGTHS
11"
RIGHT TANK TO VALVE (FUEL)
31"
LEFT TANK TO VALVE (FUEL)
A
B
